Name: Storm Conduit

Display Field: Inv_Date

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>This line feature class represents storm water conduit in the City of Independence. The conduits are designed to convey storm water runoff from storm inlet structures to storm water management facilities such as detention basins or outfalls.</SPAN></P></DIV></DIV></DIV>

Copyright Text: Municipal Services - Sewer Maintenance Division Municipal Services - Engineering Division Technology Services - GIS Division

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1.0518214344550697E7
YMin: 4724518.050728407
XMax: -1.048806208100033E7
YMax: 4741750.066704126
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: Ownership
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: Blue Springs
  Label: Blue Springs
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [193, 192, 252, 255]
  Width: 1
• Value: Independence
  Label: Independence
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 38, 115, 255]
  Width: 2
• Value: Jackson County
  Label: Jackson County
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [252, 196, 179, 255]
  Width: 1
• Value: Kansas City
  Label: Kansas City
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [187, 247, 252, 255]
  Width: 1
• Value: LBVSD
  Label: LBVSD
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [252, 182, 221, 255]
  Width: 1
• Value: Lees Summit
  Label: Lees Summit
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [252, 238, 182, 255]
  Width: 1
• Value: Not Determined
  Label: Not Determined
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [184, 252, 220, 255]
  Width: 1
• Value: Private
  Label: Private
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 85, 0, 255]
  Width: 2
• Value: Raytown
  Label: Raytown
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [238, 179, 252, 255]
  Width: 1
• Value: State of Missouri
  Label: State of Missouri
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [255, 255, 115, 255]
  Width: 2
• Value: Sugar Creek
  Label: Sugar Creek
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [227, 252, 210, 255]
  Width: 1
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: true

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Inv_Date ( type: esriFieldTypeDate, alias: Inventory Date, length: 8 )
• Conduit_ID ( type: esriFieldTypeString, alias: Conduit ID, length: 30 )
• Conduit ( type: esriFieldTypeString, alias: Conduit, length: 25 , Coded Values: [Pipe: Pipe] , [Improved Channel: Improved Channel] , [Natural Channel: Natural Channel] , ...1 more... )
• US_Struct_ID ( type: esriFieldTypeString, alias: US Struct ID, length: 25 )
• DS_Struct_ID ( type: esriFieldTypeString, alias: DS Struct ID, length: 25 )
• Conduit_Shape ( type: esriFieldTypeString, alias: Conduit Shape, length: 25 , Coded Values: [Round: Round] , [Rectangular: Rectangular] , [Horizontal Elliptical: Horizontal Elliptical] , ...4 more... )
• Conduit_Dim1 ( type: esriFieldTypeInteger, alias: Diameter/Width (in.) , Coded Values: [4: 4] , [6: 6] , [8: 8] , ...16 more... )
• Conduit_Dim2 ( type: esriFieldTypeInteger, alias: Height (in.) )
• Conduit_Material ( type: esriFieldTypeString, alias: Material, length: 25 , Coded Values: [ABS: Acrylonitrile Butadiene Styrene] , [AC: Asbestos Cement] , [BR: Brick] , ...26 more... )
• US_Inv_Depth ( type: esriFieldTypeDouble, alias: US Inv Depth (ft) )
• DS_Inv_Depth ( type: esriFieldTypeDouble, alias: DS Inv Depth (ft) )
• Comments ( type: esriFieldTypeString, alias: Comments, length: 250 )
• Status ( type: esriFieldTypeString, alias: Conduit Status?, length: 25 , Coded Values: [Active: Active] , [Other: Other] , [Abandoned In Place: Abandoned In Place] , ...1 more... )
• Ownership ( type: esriFieldTypeString, alias: Pipe Owner, length: 30 , Coded Values: [Independence: Independence] , [LBVSD: LBVSD] , [Kansas City: Kansas City] , ...8 more... )
• Install_Date ( type: esriFieldTypeString, alias: Install_Date, length: 40 )
• InstallDateSource ( type: esriFieldTypeString, alias: InstallDateSource, length: 50 )
• CouncilDistrict ( type: esriFieldTypeString, alias: Council District, length: 15 )
• Watershed ( type: esriFieldTypeString, alias: Watershed, length: 50 )
• MapGrid ( type: esriFieldTypeString, alias: Map Grid, length: 10 )
• DateLastEdited ( type: esriFieldTypeDate, alias: Date Last Edited, length: 8 )
• FacilityID ( type: esriFieldTypeString, alias: FacilityID, length: 15 )
• Pipe_Length ( type: esriFieldTypeDouble, alias: Pipe Length )
• LocationDesc ( type: esriFieldTypeString, alias: LocationDesc, length: 100 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Condition ( type: esriFieldTypeInteger, alias: Condition )
• Condition_Date ( type: esriFieldTypeDate, alias: Condition Date, length: 8 )
• LiningMethod ( type: esriFieldTypeString, alias: Lining Method, length: 4 , Coded Values: [CIP: Cured in Place] , [FF: Fold and Form or Deform/Reform] , [FP: Formed-In-Place] , ...11 more... )
• FILE_PATH ( type: esriFieldTypeString, alias: As built link, length: 255 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
